Description
DIODE GEN PURP 600V 15A TO220-2
Introducing the NHPV15S600G, a top-of-the-line diode designed for general purpose applications. With a voltage rating of 600V and a current rating of 15A, this TO220-2 package diode is engineered to deliver exceptional performance and reliability.
Built with precision and expertise, the NHPV15S600G is a must-have component for a wide range of electronic circuits. Its diode technology ensures efficient power management, allowing for seamless current flow and preventing reverse voltage spikes.
This diode's TO220-2 package provides excellent thermal conductivity, effectively dissipating heat and ensuring optimal operation even in demanding environments. Its compact design and robust construction make it suitable for various industrial and commercial applications.
Rest assured, the NHPV15S600G adheres to the highest quality standards, guaranteeing a long-lasting and dependable performance. Whether you're working on power supplies, inverters, or motor control systems, this diode is the perfect choice to meet your professional needs.
Upgrade your electronic projects with the NHPV15S600G diode – the epitome of efficiency, reliability, and excellence. Trust in its superior capabilities to enhance the performance of your circuits and ensure seamless operation for years to come.
Features
• Ultrafast 30 Nanosecond Recovery Time
• 150°C Operating Junction Temperature
• High Voltage Capability of 600 V
• ESD Ratings:Machine Model = C Human Body Model = 3A
• Low Forward Drop
• Low Leakage Specified @ 125°C Case Temperature
• These Devices are Pb−Free and are RoHS Compliant*
• NHPJ15S600G is Halogen−Free/BFR−Free
Detailed Description
| Mfr | onsemi |
| Series | - |
| Package | Tube |
| Product Status | Obsolete |
| Technology | Standard |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Current - Average Rectified (Io) | 15A |
| Voltage - Forward (Vf) (Max) @ If | 3.2 V @ 15 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 50 ns |
| Current - Reverse Leakage @ Vr | 60 µA @ 600 V |
| Capacitance @ Vr, F | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-2 |
| Supplier Device Package | TO-220-2 |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Base Product Number | NHPV15 |
Download
https://www.onsemi.com/pdf/datasheet/nhpv15s600-d.pdf
