Description
DIODE SIL CARB 650V 20A TO247-3
The FFSH4065BDN features a spacious cooking surface that allows you to cook multiple dishes simultaneously,
saving you time and effort. Its advanced induction technology ensures fast and even heating,
delivering precise temperature control for perfect results every time.
Operating the FFSH4065BDN is a breeze, thanks to its user-friendly touch controls. With just a simple touch,
you can select your desired cooking mode and adjust the temperature to suit your recipe.
The cooktop's digital display provides clear and intuitive feedback, allowing you to monitor and fine-tune your cooking settings with ease.
Safety is a top priority with the FFSH4065BDN. It is equipped with a child lock function that prevents accidental operation,
ensuring the safety of your little ones. Additionally, the cooktop automatically shuts off after a period of inactivity,
giving you peace of mind and conserving energy.
Type: Diode (Exact type not specified, but based on the package, it's likely a rectifier or Schottky diode.)
Maximum Voltage Rating: 650V
Maximum Current Rating: 20A (or 20000mA)
Package: TO-247-3 (also known as TO-3P or TO-3PN)
Features and Applications:
The FFSH4065BDN diode, based on the specifications, is designed for various electronic applications that require high voltage and current capabilities, such as:
Rectification: It can be used for converting alternating current (AC) to direct current (DC) in power supplies and voltage rectification circuits.
High-Power Applications: With its high voltage and current ratings, it is suitable for high-power applications like power electronics, motor drives, and inverters.
High-Voltage Protection: It can be used as a high-voltage protection diode in circuits to prevent damage from voltage spikes.
The TO-247-3 package is a through-hole package that provides better heat dissipation and mechanical stability compared to some surface-mount packages.
Features
• Max Junction Temperature 175°C
• Avalanche Rated 94 mJ
• High Surge Current Capacity
• Positive Temperature Coefficient
• Ease of Paralleling
• No Reverse Recovery/No Forward Recovery
• AEC−Q101 Qualified
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
Detailed Description
| Mfr Part # | FFSH4065BDN-F085 |
| Mfr | onsemi |
| Series | Automotive, AEC-Q101 |
| Package | Tube |
| Product Status | Active |
| Technology | SiC (Silicon Carbide) Schottky |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Current - Average Rectified (Io) | 20A |
| Voltage - Forward (Vf) (Max) @ If | 1.7 V @ 20 A |
| Speed | No Recovery Time > 500mA (Io) |
| Reverse Recovery Time (trr) | 0 ns |
| Current - Reverse Leakage @ Vr | 40 µA @ 650 V |
| Capacitance @ Vr, F | 866pF @ 1V, 100kHz |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | TO-247-3 |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Base Product Number | FFSH4065 |
Download
