Description
FIXED IND 1UH 5A 12 MOHM SMD
Detailed Description
| Mfr Part # | SRN5040TA-1R0M |
| Mfr | Bourns Inc. |
| Description | FIXED IND 1UH 5A 12 MOHM SMD |
| Stock | 923 |
| Price | 0.6 |
| @ qty | 0 |
| Min Qty | 1 |
| Package | Tape & Reel (TR),Cut Tape (CT) |
| Series | SRN5040TA |
| Part Status | Active |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 1 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 5 A |
| Current - Saturation (Isat) | 7.5A |
| DC Resistance (DCR) | 12mOhm |
| Q @ Freq | 15 @ 100kHz |
| Frequency - Self Resonant | 140MHz |
| Size / Dimension | 0.195" L x 0.195" W (4.95mm x 4.95mm) |
| Height - Seated (Max) | 0.161" (4.10mm) |
SRN5040TA Series-Semi-shielded Power Inductors Features
*Semi-shielded construction
*Inductance range: 0.6 to 100 µH
*Rated current up to 8 A
*AEC-Q200 compliant
*RoHS compliant* and halogen free
Applications
*DC/DC converters
*Power supplies
Download
