Description
FIXED IND 680NH 7.6A 18 MOHM SMD
Detailed Description
| Mfr Part # | SRP0512-R68K |
| Mfr | Bourns Inc. |
| Description | FIXED IND 680NH 7.6A 18 MOHM SMD |
| Stock | 4,295 |
| Price | 1.16 |
| @ qty | 0 |
| Min Qty | 1 |
| Package | Tape & Reel (TR),Cut Tape (CT) |
| Series | SRP0512 |
| Part Status | Active |
| Type | - |
| Material - Core | Metal |
| Inductance | 680 nH |
| Tolerance | ±10% |
| Current Rating (Amps) | 7.6 A |
| Current - Saturation (Isat) | 11A |
| DC Resistance (DCR) | 18mOhm Max |
| Q @ Freq | 17 @ 25.2MHz |
| Frequency - Self Resonant | 58MHz |
| Size / Dimension | 0.213" L x 0.201" W (5.40mm x 5.10mm) |
| Height - Seated (Max) | 0.047" (1.20mm) |
SRP0512 Series - Shielded Power Inductors Features
*Shielded construction
*Metal alloy powder core
*High saturation current
*Low buzz noise
*Flat wire
*RoHS compliant* and halogen free**
Operating Temperature：40 °C to +125 °C
Storage Temperature (Component)：-40 °C to +125 °C
