Description
FIXED IND 220NH 70A 0.18MOHM SMD
Detailed Description
| Mfr Part # | VLBU1007090T-R22L |
| Mfr | TDK Corporation |
| Description | FIXED IND 220NH 70A 0.18MOHM SMD |
| Stock | 969 |
| Price | 2.82 |
| @ qty | 0 |
| Min Qty | 1 |
| Package | Tape & Reel (TR),Cut Tape (CT) |
| Series | VLBU |
| Part Status | Active |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 220 nH |
| Tolerance | ±15% |
| Current Rating (Amps) | 70 A |
| Current - Saturation (Isat) | 57A |
| DC Resistance (DCR) | 0.18mOhm |
| Q @ Freq | - |
| Inductance Frequency - Test | 100 kHz |
| Package / Case | Nonstandard |
VLBU1007090T-R22L APPLICATION：Servers, BTS, VRM, others
VLBU1007090 type FEATURES
This is a power supply circuit for SMD inductors using ferrite materials.
Large current and lower DCR were achieved by the connecting wire-less structure.
Direct current-sensing properties under high temperature conditions are good, too.
Operating temperature range: –40 to +125°C (including self-temperature rise).
Introducing the VLBU1007090 series fixed inductor, designed to cater to the growing demand for high-performance inductors in the technology industry. Our product is engineered to provide superior performance and reliability, making it the perfect choice for tablet terminals, Servers, BTS, VRM, others compact power supply modules, and other applications.
Our VLBU1007090 series fixed inductor is specifically designed to meet the needs of the modern-day technology industry. With its compact size and advanced features, it is the ideal choice for smart phones and tablets. Our product is built to withstand the rigors of daily use, ensuring that your devices operate smoothly and efficiently.
Our inductor is made using the highest quality materials and advanced manufacturing techniques, ensuring that it meets the highest standards of quality and performance. It is designed to provide exceptional performance at high frequencies, making it the perfect choice for demanding applications.
Whether you are looking for a reliable inductor for your tablet terminals or other technology devices, our VLBU1007090 series fixed inductor is the perfect choice. With its advanced features and exceptional performance, it is sure to meet all your needs and exceed your expectations. So why wait? Order yours today and experience the difference for yourself!
Download
