Description
FIXED IND 100NH 65A 0.2 MOHM SMD
Detailed Description
| Mfr Part # | VLBU805080T-R10L |
| Mfr | TDK Corporation |
| Description | FIXED IND 100NH 65A 0.2 MOHM SMD |
| Stock | 1,791 |
| Price | 2.55 |
| @ qty | 0 |
| Min Qty | 1 |
| Package | Tape & Reel (TR),Cut Tape (CT) |
| Series | VLBU |
| Part Status | Active |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 100 nH |
| Tolerance | ±15% |
| Current Rating (Amps) | 65 A |
| Current - Saturation (Isat) | 75A |
| DC Resistance (DCR) | 0.2mOhm |
| Q @ Freq | - |
| Inductance Frequency - Test | 100 kHz |
| Package / Case | Nonstandard |
VLBU805080T-R10L APPLICATION：
Servers, BTS, VRM, others
FEATURES：
Large current and lower DCR were achieved by the connecting wire-less structure.
This is a narrow inductor for multiphase applications.
Operating temperature range: –40 to +125°C (including self-temperature rise)
Introducing the VLBU805080 series fixed inductor, designed to cater to the growing demand for high-performance inductors in the technology industry. Our product is engineered to provide superior performance and reliability, making it the perfect choice for HDDs, servers, VRMs, compact power supply modules, and other applications.
Our VLBU805080 series fixed inductor is specifically designed to meet the needs of the modern-day technology industry. Our product is built to withstand the rigors of daily use, ensuring that your devices operate smoothly and efficiently.
Download
